| ENGINE | Single cylinder, horizontal, four stroke, forced air cooling (oil cooler can be added) |
| Bore x Stroke | 65*60 |
| Compression ratio | 9.5:1 |
| Carburetor |
|
| Ignition | CDI |
| Starting time | Electric start |
| Transmission |
|
| Drive train | Belt Drive |
| Max. Torque | 13.5 n.m/5500r/min |
| Max. Power | 49.3kw/7000r/min. |
| CHASSIS |
|
| Suspension/Front | Independent double swing arm |
| Suspension/Rear | Single swing arm |
| Brakes/Front | Ventilated Hydraulic disc |
| Brakes/Rear | Ventilated Hydraulic disc |
| Tires/Front | 25*8 -12 radial |
| Tires/Rear | 25*10-12 radial |
| DIMENSIONS |
|
| L x W x H | 2700mmX1450mmX1940mm |
| Seat height |
|
| Wheelbase |
|
| Ground clearance | 300mm |
| Battery | 12V/9Ah |
| Fuel capacity | 23L |
| Net weight | 452KG |
| Max. Load | 360KG |
| Package size | 2330*1460*1260 |
| Loading quantity | 16pcs/40HQ |
| MAIN PERFORMANCE |
|
| Max. Speed | 65km/h |
| Fuel consumption | 3.3L/100kg |
| Starting time | ≤15s |
| Brake distance |
|
